OEM Pressure Transmitters for heavy-duty mobile hydraulic applications
The compact OEM pressure transmitter program is designed for use in severe hydraulic applications. The program consists of three series:
- DST P600 - without integrated pulse snubber
- DST P650 - with integrated pulse snubber
View the 3D models:
The integrated pulse-snubber offers a high degree of protection against cavitation and liquid hammer, and the well thought out design results in excellent vibration stability and an exceptional robustness. The high degree of EMI protection equips the pressure transmitter to meet most requirements. Running a powerful ARM-based micro-controller, offering diagnostic functions and intelligent performance features.
Features and benefits
MTTFd >100 years
High burst and over pressure capabilities due to fully welded design.
Safe ingress protection even in the harshest environment.
EMC protection up to 100 V/m
EMC tested in accordance with Automotive ISO standards
Zero drift due to excellent long term stability ensuring safety of the machine.
High tolerance to mechanical shock and vibrations
Fully digitally compensated
Wetted parts of stainless steel
Wide range of electrical and pressure connections
For medium and ambient temperatures up to 125 °C
Output clipping Min and Max
Product ordering key
Please contact your local Danfoss Office for further information.
130% increase in production capacity and the next-generation DST P650 pressure transmitter is available?
On the heels of our boosted pressure transmitter production capacity, Danfoss is launching the DST P650, a robust digital-ready pressure transmitter delivering future-proof efficiency, reliability, and safety
Documents
| Type | Name | Language | Valid for | Updated | Download | File type |
|---|---|---|---|---|---|---|
| Brochure | DST P650 - a robust, digital-ready pressure transmitter built for reliable performance in intense mobile hydraulic applications. | English | Multiple | 11 Oct, 2023 | 2.6 MB | |
| Data sheet | OEM Pressure Transmitters for heavy-duty applications, Type DST P600 and DST P650 | English | Multiple | 23 Jun, 2023 | 1.2 MB |
Approvals
CE
RoHs
UL
MTTFd >100 years in accordance with ISO13849-1
Tested in accordance with ISO automotive references
Approval Certificates
