Evaporator controls for a variety of refrigerants and operating ranges
Danfoss offers a range of evaporator controls with thermostatic expansion valves or with electric expansion valves. The valves can be used for a variety of refrigerants and operating ranges suited for food retail applications.
The evaporator controls with electric expansion valves are designed to ensure precise control of the injection of refrigerant liquid into the evaporators to ensure optimum performance and low energy consumption.
The evaporator controls from Danfoss have functions for regulating/monitoring temperature, defrosting, doors, rail heating, light and fan operation.
With remote communication as a part of ADAP-KOOL® refrigeration control system, evaporator controls comprise monitoring and control of display cases and cold rooms including alarm monitoring. The Danfoss electric expansion valves enable adaptive, automatic refrigeration control with no manual setting required. This provides additional energy savings.
Introducing a new family of entry-level case/refrigeration controllers for Food retail applications: EKC 223/EKC 224
The new EKC 22x family brings modern, yet familiar design, convenient setting menu navigation, support for different sensor types, 16A compressor relay, and system integration to Danfoss front ends via EKA 206 RS-485 (Modbus) adapter.
AK-CC55 series
Danfoss offers a solution that makes it easier than ever to save on adaptive and reliable food retail refrigeration. The new AK-CC55 case controls deliver energy savings of 6-10% compared to the next best alternative. It relies on acknowledged and advanced Danfoss adaptive super-heat algorithms to control refrigerated display cases and cold rooms.
The new ADAP-KOOL® Case Control generation ensures the system providing the same great value as always and now delivers a much better user experience, no matter if you’re an OEM, installer, service technician, or food retailer. For example, the large terminals on the AK-CC55 make it easy to loop the pressure transmitter cable from one controller to the next one.
Features and benefits
Significant energy savings with adaptive super-heat control algorithms and adaptive defrost.
Simplified installation and service with smartphone app and large terminals.
Suitable for any store size with Compact, Single Coil, and Multi Coil variants.
Explore Our New CO₂ Product Catalogue!
We have collected all our products and solutions for CO2 and equipped each with a unique code number for easy reference, you can now explore our CO2 solutions effortlessly.
Take user friendliness to the next level with AK-CC55 Connect app
AK-CC55 Connect app is an industry first wireless tool for configuration and service of AK-CC55 controlling refrigerated display cases and cold rooms.
Getting supermarkets to net zero
With the world’s population expected to reach 10 billion people by 2050, sustainable food retail and storage are more important than ever. Yet this is an often-overlooked step in the decarbonization of society.
