Heating mats

The outdoor heating mats are designed for melting ice and snow and may be installed into special mastic for ground, grass and asphalt constructions. Mats are available in different lengths for two power supply options: 230 and 400 V.​​
​
The heating mats are also recommended for installation under artificial grass (e.g. football fields).​

DEVIasphalt™ / ECasphalt​
DEVIasphalt™ / ECasphalt​

DEVIasphalt™ / ECasphalt​ ready-made heating cable mat is an extremely high-quality, 360°, fully screened, twin conductor cable with a very robust outer sheath (UV resistant) fixed on the plastic mesh. It is designed especially for embedding directly into max. 240°C mastic or asphalt concrete (road asphalt).​
​
Applications:​
• Road/concrete asphalt​
• Mastic asphalt

DEVIsnow™ / ECsnow
DEVIsnow™ / ECsnow

DEVIsnow™ / ECsnow ready-made heating cable mat is an extremely high-quality, 360°, fully screened, twin conductor, heating cable with a tough outer sheath (UV resistant) fixed by plastic tapes. Its round profile and robust construction ensure a fast, simple, and safe installation on the ground​
​
Applications:​
• Ground, walkways, outdoor steps​
• Ramps, bridges

ECsafe
ECsafe

ECsafe ready-made heating cable mat is an extremely high-quality, 360°, fully screened, twin conductor heating cable (UV resistant) fixed by plastic tapes. Its round profile and robust construction ensure a fast, simple and safe installation on the ground.​
​
Applications:​
• Ground, walkways, outdoor steps​
• Ramps, bridges

Features and benefits using outdoor heating mats

Easy and fast installation​

Efficient snow removal - area is kept free from ice and snow 24/7​

Safe traffic and working areas for people​

Cost saving for outdoor surface repair after winter​

A maintenance free system with 20 year full warranty on cables​

Avoiding unforeseen repair costs ​

Suitable for special solutions e.g. asphalt, grass and different types of bricks

Related products

Accessories

Relevant accessories

Relevant accessories

Find relevant accessories by following this link

Accessories in Product Store

Videos

Snow melting and De-Icing solutions from Danfoss

Snow melting and De-Icing solutions from Danfoss

Durably-designed Danfoss snow melting and de-icing products provide a permanent solution for safety in winter weather.

Electric heating videos on YouTube

Electric heating videos on YouTube

You can see all our videos about Electric Heating on a dedicated playlist on YouTube. Follow the link below.

Go to the Electric Heating playlist on YouTube

Documents

Documents
Type Name Language Valid for Updated Download File type
Application guide Danfoss Ground application. Ice & Snow Melting Application manual English Multiple 11 Nov, 2020 7.5 MB .pdf
Catalog Danfoss Product catalogue English Multiple 20.8 MB .pdf
Application guide Danfoss Sports Field Heating English Multiple 11 Nov, 2020 932.4 KB .pdf
Application guide DEVI Asphalt Application manual Romanian, Moldavian, Moldovan Romania 29 May, 2024 7.2 MB .pdf
Application guide DEVI Asphalt Application manual Lithuanian Lithuania 21 May, 2024 7.2 MB .pdf
Application guide DEVI Asphalt Application manual Danish Denmark 06 Jun, 2024 4.7 MB .pdf
Application guide DEVI Asphalt Application manual Russian Kazakhstan 20 May, 2024 7.2 MB .pdf
Application guide DEVI Asphalt Application manual Swedish Sweden 22 Jun, 2022 7.1 MB .pdf
Application guide DEVI Asphalt Application manual English Multiple 16 May, 2024 7.2 MB .pdf
Application guide DEVI Asphalt Application manual Ukrainian Ukraine 10 Jun, 2024 4.8 MB .pdf
Data sheet DEVIasphalt™ 300T - 230 V & 400 V English Multiple 22 Feb, 2024 291.1 KB .pdf
Data sheet DEVIasphalt™ 300T - 230V (DTIK) Danish Denmark 19 Oct, 2022 226.6 KB .pdf
Data sheet DEVIasphalt™ 300T - 230V (DTIK) French France 03 Oct, 2024 268.6 KB .pdf
Data sheet ECasphalt 300T 230V and 400V English Multiple 17 Jul, 2023 425.9 KB .pdf
Data sheet ECsafe 100T 230V and 400V English Multiple 17 Jul, 2023 445.4 KB .pdf
Data sheet ECsnow 250T 400V English Multiple 23 Jul, 2020 338.5 KB .pdf

Tools and apps

EH Plugin for AutoCAD
EH Plugin for AutoCAD

The Plugin supports your engineering and design journey by making your work faster due to simple functionalities in calculating all lengths, dimensions and product data of cables and mats. It covers all applications within Electric Heating projects: Electric floor heating, Ice & Snow melting systems, Pipe tracing, Cold stores, Sport fields, Vineyards etc.
By utilizing Plugin, you will reduce design time for the project, provide all necessary information for installers in HTML/PDF format: BoM, resistance value check list, warranty list format. It means all project information can be consolidated in one file.

Plugin can be used with AutoCAD 2017-2023.

Warranty

Warranty

At Danfoss, it is important for us to deliver high-quality products with long-lasting effects. Should you, against all expectations, experience a problem with your product, Danfoss offers a warranty for electric heating products valid from the date of purchase that was no later than 2 years from production date.

Depending on the product, the product guarantee is valid for two years, five years, or twenty years.

Product warranty covers costs for:

  • product replacement with a new comparable product or repair of the product
  • transportation costs
Warranty terms

Case stories

  • if (isSmallPicture) { Remarkable solution for Remarkables Ski Field Queenstown, New Zealand; } else if (isBigColumns) { Remarkable solution for Remarkables Ski Field Queenstown, New Zealand } else { Remarkable solution for Remarkables Ski Field Queenstown, New Zealand }
    Remarkable solution for Remarkables Ski Field Queenstown, New Zealand

    The Remarkables Ski Field is one of New Zealand's premier ski fields, located at a longitude of 45.05 degrees South, elevation 1,586 m, and situated near the North end of the Remarkables range. The base building has approximately 2,500 m² of heated outdoor patio at a density of 200 W/m². The heating of the patio matches the needs and requirements to prevent the surface accumulation of ice in a modern and highly efficient way.

  • if (isSmallPicture) { An ideal field is an integral part of a successful game; } else if (isBigColumns) { An ideal field is an integral part of a successful game } else { An ideal field is an integral part of a successful game }
    An ideal field is an integral part of a successful game

    For professional and international stadiums, a very high standard of playing surface is required. It is important to eliminate the risk of match cancellations, particularly those associated with poor weather conditions e.g. heavy rainfall or ice and snow.

Related applications

  • if (isSmallPicture) { Agriculture; } else if (isBigColumns) { Agriculture } else { Agriculture }
    Agriculture

    Farmers need agricultural machines that deliver the same high productivity every season. Hydraulic solutions from Danfoss ensure world-class performance from each machine, and a comfortable, stress-free working environment for their operators.



  • if (isSmallPicture) { Electric heating frost and snow protection system used in application in pavement; } else if (isBigColumns) { Electric heating frost and snow protection system used in application in pavement } else { Electric heating frost and snow protection system used in application in pavement }
    Electric heating frost and snow protection system used in application in pavement

    Ice and snow melting systems are used in various applications in parking lots, garages, stairs, pavements, and other ground-level surfaces. They secure personal safety in hazardous winter conditions. Our systems can be installed on roofs, in gutters, pavements, and many more areas in and around the house. There is a wide range of products available such as cables or heating mats, specialized controllers, and mounting accessories. And you can count on us for knowledgeable support and service.

  • if (isSmallPicture) { ; } else if (isBigColumns) { } else { }
    Frost and snow protection

    During winter time it can be hazardous to access commercial or public buildings. Snow covered parking lots, garage ramps, stairs and pavements need to be cleaned to allow visitors safe access. Danfoss offers highly effective frost and snow protection systems including all necessary products such as electric heating cables or mats, controllers, sensors and mounting accessories.
