VLT® Decentral Drive FCD 302

Get a quote
  • Overview
  • Documents
  • 3D models and drawings
  • Software
  • Related applications
  • Case stories
Get a quote

The best fit for direct machine mounting

Designed for simplicity and robustness, the VLT® Decentral Drive FCD 302 is a user-friendly product with high performance and a strong protection degree.

A decentral-drive solution eliminates the need for space-consuming control cabinets. And, with the drives placed near the motor, there is no need for long-screened motor cables.

With the VLT® Decentral Drive FCD 302, all the options are built into the unit reducing the number of boxes to be mounted, and the connections and terminations in the installation. As a result, labor costs and the risks of failure are dramatically reduced.

Supply voltages and power range

  • 3 x 380-480 V...0.37-3 kW

Features and benefits

Installation is flexible as the drive adapts to any brand of motor

Servicing is fast and easy due to the pluggable twin-part design

Cleaning is easy thanks to the drive’s smooth surface

Cable savings are possible as a result of the integrated power and fieldbus looping terminals

Direct connection to a PC is possible thanks to the integrated USB port

The need for PLC capacity is reduced due to the built-in smart logic controller
