EV220B, servo-operated solenoid valves

Servo-operated solenoid valves for multiple applications

EV220B 6-22 is a direct servo-operated 2/2-way solenoid valve program with connections from 1/4" to 1". This program is especially for OEM applications demanding a robust solution and moderate flow rates.

EV220B 15–50 is a universal indirect servo-operated 2/2-way solenoid valve program. Valve body in brass, dezincification resistant brass and stainless steel ensures that a broad variety of application can be covered.

Built-in pilot filter as standard, adjustable closing time and enclosures up to IP67 ensures optimal performance even under critical working conditions.

EV220B 65 - 100 is a 2/2-way solenoid valve program for use in robust industrial applications, demanding high flow rates. The valve is designed with cast iron valve body and flanged connection. Water-hammer damped design and built-in pilot filter ensures a reliable operation.

Features and benefits

EV220B 6-22

For water, oil, compressed air and similar neutral media
Flow range from 0.2 – 19 m³/h
Differential pressure from 0.1 – 20 bar
Coil enclosure: Up to IP67
Thread connections: From G ¼ – G 1
DN 6 – 22
Viscosity: Up to 50 cSt
Brass version NC and NO
DZR brass version NC
FKM and EPDM
Also available with NPT thread

EV220B 15-50

For water, steam, oil, compressed air and gases
Flow range for water: 1.3 – 160 m³/h
Differential pressure: 0.3 – 16 bar
Coil enclosure: Up to IP67
Thread connections: From G ½ – G 2
DN 15 – 50
Viscosity: Up to 50 cSt
Water hammer damped
Built in filter for protection of pilotsystem
Adjustable closing time available
EV220B NC and NO brass version for neutral liquids and gasses
EV220BD NC DZR version for neutral and slightly aggressive liquids and gases
EV220BSS NC Stainless steel version for neutral and aggressive liquids and gases
Also available with NPT thread

EV220B 65-100

For water and similar neutral media
Flow range for water: 25 – 400 m³/h
Differential pressure: Up to 10 bar
Viscosity: Up to 50 cSt
Coil enclosure: Up to IP67
Flange connections: 2 1/2, 3 and 4”
Water hammer damped
Built-in filter for protection of pilot system
Seal material: EPDM and NBR

The safe choice for drinking water

WRAS and RISE approved solenoid valves ensure your compliance. Danfoss solenoid valves are the clever choice for installers and the safe choice for drinking water.

X-ray of an industrial solenoid valve promoting the valve selector tool by Danfoss

Find the right valves

The tool is intended to make it easy for installers and end-users to specify the correct industrial solenoid valves for a range of standard applications.

Go to the valve selector

Documents

Documents
Type	Name	Language	Valid for	Updated	Download	File type
Installation guide	EV220B 15-50 Normally Closed/ Normally open (NC/NO	German; English; French	Multiple	06 Jun, 2011	2.6 MB	.pdf
Data sheet	Servo-operated 2/2-way solenoid valves EV220B 15-50	Polish	Multiple	07 Oct, 2024	20.9 MB	.pdf
Data sheet	Servo-operated 2/2-way solenoid valves EV220B 15-50	Chinese (CN)	Multiple	07 Oct, 2024	20.9 MB	.pdf
Data sheet	Servo-operated 2/2-way solenoid valves EV220B 15-50	Spanish, Castilian	Multiple	07 Oct, 2024	20.8 MB	.pdf
Data sheet	Servo-operated 2/2-way solenoid valves EV220B 15-50	French	Multiple	07 Oct, 2024	20.8 MB	.pdf
Data sheet	Servo-operated 2/2-way solenoid valves EV220B 15-50	Italian	Multiple	07 Oct, 2024	20.8 MB	.pdf
Data sheet	Servo-operated 2/2-way solenoid valves EV220B 15-50	German	Multiple	07 Oct, 2024	20.9 MB	.pdf
Data sheet	Servo-operated 2/2-way solenoid valves EV220B 15-50	Portuguese	Multiple	07 Oct, 2024	20.8 MB	.pdf
Data sheet	Servo-operated 2/2-way solenoid valves Type EV220B 15 - EV220B 50	English	Multiple	07 Oct, 2024	20.6 MB	.pdf
Data sheet	Solenoid valve Type EV220B	English	Multiple	05 Dec, 2024	14.8 MB	.pdf
Installation guide	Solenoid valve Type EV220B 15 - EV220B 50	English	Multiple	26 Jul, 2023	1.2 MB	.pdf
