Flexible, robust and serviceable
The enclosed VACON® NXC is the compact drive that performs reliably in harsh operating conditions in, for example, the mining, oil and gas or water and wastewater industries. The thermally managed enclosure extends drive lifetime and ensures trouble-free operation.
The enclosures, which feature lifting lugs for easy handling, can be either wall-mounted or free-standing. The easily accessible control compartment for relays, auxiliary terminals and other equipment, and ample space around the power terminals ensure straightforward installation and connection of power cables. And the mounting rails and pull-out jig enable fast and efficient servicing of the power unit.
Supply voltages and power range
6- and 12-pulse supplies:
- 3 x 380-500 V...132-1200 kW
- 3 x 525-690 V...110-2000 kW
AFE supplies:
- 3 x 380-500 V...132-1500 kW
- 3 x 525-690 V...110-2000 kW
Low Harmonic, Active Filter supplies:
- 400 V.....132-560 kW
- 500 V*...132-560 kW
- 690 V.....110-800 kW
*requires 690 V active filter
Features and benefits
Lower investment cost as no extra design, engineering or additional cooling fans are needed
Reduced commissioning and servicing time due to easily accessible control compartment and removable keypad
Improved serviceability thanks to mounting rails and service concept with pull-out jig
Lower maintenance costs due to robust, type-tested design
