Safe construction for the most demanding requirements

Danfoss GBC  ball valves are manually controlled, bi-directional shut-off valves. GBC valves are designed for liquid, suction, and hot gas lines in refrigeration systems and are available with or without an external access port.

The design, welding, and sealing material provide safe construction suited for even the most demanding requirements, such as working with R-410A under high-pressure.

Features and benefits

Broad temperature range allows for use in air conditioning, refrigeration, and freezing applications

Laser-welded, custom-made brass construction produces consistent performance, even under aggressive operational conditions

Rupture-proof, internally loaded spindle design guarantees safe operation, even under extreme pressures

Double O-ring stem seal design ensures long product life with zero leakage

Ball status indicator on spindle top confirms valve position

Bi-directional flow design enables valve to oriented in any direction

Getting supermarkets to net zero

With the world’s population expected to reach 10 billion people by 2050, sustainable food retail and storage are more important than ever. Yet this is an often-overlooked step in the decarbonization of society.

Documents

Documents
Type Name Language Valid for Updated Download File type
Brochure GBC & NRV for CO2 applications English Multiple 10 Nov, 2014 1.0 MB .pdf
Data sheet Shut-off ball valve, type GBC (90 bar) and GBCT (140 bar) English Multiple 29 Dec, 2023 5.9 MB .pdf
